The Lynx Studio Technology AES16 multi-channel interface is the ideal way to integrate digital consoles, multi-channel A/D and D/A converters, and hard disk recorders with computer-based workstations. Using exclusive SynchroLock technology, jitter is eliminated for the purest conversions possible, and the AES16 supports sample-rates up to 192kHz. Large, on-board buffers ensure glitch-free recording and playback, aided by an extremely efficient zero-wait state DMA engine. These features provide tolerance to system latencies and significantly reduce load on the host CPU. The AES16 is a great centerpiece of a digital studio.Supports up to 16 channels of 192kHz audio I/O The AES16 offers unprecedented AES/EBU channel capacity and routing flexibility in a single PCI card format. With support for up to 16 channels of input and output at sample rates up to 192kHz, the AES16 turns your computer into a powerful digital router or patchbay with extensive flexibility with minimal cabling. Most importantly, the AES16 supports the emerging single-wire 192kHz standard and is compatible with existing dual-wire AES/EBU devices. Up to four AES16s can be installed in a single computer. Exclusive SynchroLock technology assures jitter-free performance Offering a solution for jitter problems in AES signals, the AES16 incorporates a new Lynx technology called SynchroLock that provides extreme jitter tolerance at all inputs. By coupling statistical analysis with low-noise clock generation techniques, SynchroLock is able to extract a very clean clock from AES signals affected by long cable lengths and other noise sources. The clock output of SynchroLock can also be used as a very accurate word clock source for other studio devices. Supports up to 16 channels of 192kHz audio I/OExclusive SynchroLock technology assures jitter-free performanceLow-latency performance and reduced CPU loadMastering-grade sample rate conversionOnboard digital mixer Für weitere Informationen, besuchen Sie bitte die Homepage zu diesem Produkt.
Digital Audio Referenz Wandler... Lynx AES16e-SRC wie Lynx AES16e jedoch mit zuschaltbarer 16 Kanal Sampleraten Wandlung Die Lynx AES16e bietet jeweils 16 Ein-und Ausgangskanäle mit 192 kHz AES/EBU. Zusätzlich zum Basismodell beherrscht die Lynx AES16e-SRC die Sampleraten Wandlung auf 16 Kanälen. Die Lynx AES16e baut auf den Fähigkeiten unserer Lynx AES16 auf, die seit Jahren der Industriestandard bei Multikanal AES/EBU Audio Interfaces ist, bringt jedoch eine Reihe von Verbesserungen mit und paßt in moderne PCI Express Steckplätze aktueller Windows und Mac OSX Audio Workstations. Die Architektur und die höhere Bandbreite des PCI Express Standards reduziert Flaschenhälse und Überlastung, was automatisch zu einer spürbar höheren Leistung für computerbasiertes HighEnd Audio führt. Die Lynx AES16e x1 PCI Express Karte besitzt jeweils 16 Ein- und Ausgangskanäle für 24 Bit AES/EBU Digital Audio bei einer Samplerate von 192 kHz, sowohl im Single-Wire, als auch im Dual-Wire AES Modus. Die Lynx AES16e wurde speziell designed für die Integration von digitalen Mischpulten, Multikanal A/D und D/A Wandlern, Harddisk Recorder, digitale Audio Workstations und anderem digitalem Audioequipment und funktioniert sowohl unter Windows als auch unter Macintosh Betriebssystemen. Die Lynx AES16e-SRC ermöglicht die Sampleraten Wandlung auf 16 Kanälen, welche wahlweise entweder auf die Eingänge oder die Ausgänge wirkt. Für weitere Informationen, besuchen Sie bitte die Homepage zu diesem Produkt.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
16 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
DANTE Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
16 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
ProTools®|HD Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
16 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
Thunderbolt Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
16 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
USB Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
24 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
DANTE Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
24 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
ProTools®|HD Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
24 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
Thunderbolt Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
32 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
DANTE Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
32 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
ProTools®|HD Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
32 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
Thunderbolt Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
8 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
DANTE Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
8 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
ProTools®|HD Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
8 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
Thunderbolt Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Der Aurora definierte die Standards in Transparenz, Zuverlässigkeit und Wertstabilität für professionelle A/D D/A Wandler und ist Mittelpunkt professioneller Aufnahmestudios auf der ganzen Welt. Der komplett neu entwickelte Aurora(n) führt dieses Vermächtnis fort.
Das Wichtigste im Überblick:
8 Kanal Version - jeweils auf einer Höheneinheit.
24 Bit / 192 kHz Mastering Qualität über alle Kanäle gleichzeitig.
USB Interfacekarte.
Onboard 32 Kanal microSD Rekorder für direkte Aufnahme und Wiedergabe.
Zwei audiophile Kopfhörerausgänge mit unabhängigen Lautstärkereglern.
1 IN, 3 OUT Wordclock, gepaart mit der neu entwickelten Lynx SynchroLock 2™ Technologie.
Kompromißlose Windows und OSX Kompatibilität.
Road-taugliches, verstärktes Rack-Chassis.
Eight channels of analog input in a 5 meter / 16.4 foot cable. TASCAM wiring standard. One needed for the Aurora 8 and two for the Aurora 16. Male 25 pin DSub to eight XLR female connectors. Für weitere Informationen, besuchen Sie bitte die Homepage zu diesem Produkt.
Lynx CBL-DIGY85 Digital input/output cable; eight channels AES/EBU I/O. Male 25 pin D-sub connector (yellow) with four female XLR connectors for input and four male XLR connectors for output; 5 meters (16.4 feet) long; Yamaha pinout configuration. Für weitere Informationen, besuchen Sie bitte die Homepage zu diesem Produkt.
Eight channels of analog output in a 5 meter / 16.4 foot cable. TASCAM wiring standard. One needed for the Aurora 8 and two for the Aurora 16. Male 25 pin DSub to eight XLR male connectors.
Overview
Lynx Studio Technology is proud to present the Hilo Reference A/D D/A Converter System. With the pristine, open, transparent audio quality for which Lynx is known, Hilo (pronounced HE-low) provides two channels of mastering quality analog to digital conversion, up to six channels of digital to analog conversion, a secondary monitor output, and a world class independent headphone amplifier in a compact half-rack size. A first for the two-channel pro converter market, Hilo’s innovative 480 x 272 touch-screen provides a flexible and intuitive interface that can adapt to a particular application and be easily upgraded with enhancements and new features. Front panel controls support extensive signal routing and mixing, sample rate selection, clock source options, levels, metering and diagnostic features.
Hilo completely redefines and evolves the category of the two channel converter. Of utmost importance is the audio signal quality. The completely new design of the analog stages and converter topology for Hilo break new ground in terms of lowering distortion and noise while maintaining transparency for A/D and D/A conversion. Beyond that, Hilo offers extensive I/O capabilities and utilizes the latest FPGA technology with vast resources for control, routing, and signal processing capabilities. Also in development are diagnostic and analysis tools for Hilo. The LCD screen is a natural interface for these functions.
The digital or analog inputs can be routed to three separate analog outputs, Line Output (with 8 trim settings), Monitor Output, and Headphone Output. Each of these output pairs has its own dedicated DACs, allowing each to offer a unique mix. The Monitor and Headphone Outputs have volume controls, accessible via faders on the touch-screen or the single knob on the front (offering control in ½ dB increments). Another innovation, the Headphone section has its own dedicated D/A converter. This supports the creation of 32-channel headphone mixes independent of the main and monitor outputs, as well as providing specifications that rival those of dedicated headphone amps costing $1500 and more.
The digital section offers a wide range of inputs. AES/EBU inputs and outputs have transformer isolated balanced XLR connectors. S/PDIF input and output are available via transformer-coupled coax or optical (TOSLINK) connections. The Optical ports can also be used for up to eight ADAT channels. The ADAT input and output channels are completely independent from the AES/EBU or S/PDIF coax channels. The Lynx LT-USB (USB 2.0) or LT-TB (Thunderbolt) LSlot accessory is also included, for computer connectivity. The LT-HD for Pro Tools HD connectivity is also enabled. Lynx’s low jitter SynchroLock word clock is included, with Word Clock in and out connections available.
In total, Hilo has 12 total inputs, 16 total outputs plus 32 channels possible via its LSlot port. The unit’s FPGA powers its internal 32-channel mixer, which allows Hilo to offer the most versatile I/O and routing in the two channel converter genre.
In contrast to the concentrated and intricate back panel, Hilo’s front panel is elegant in its simplicity. It has a power switch, headphone jack, multipurpose control and a 480 x 272 pixel high resolution LCD touchscreen. This high-resolution screen does a lot more than simply replace the buttons on the front panel of most other converters. Of course it handles the basic settings and routing functions, clocking and level settings.
A second meter screen shows just two larger bar-graph style stereo bar meters. Any input or output set can be assigned to each meter. In addition to bar-graph meters common on most converters, Hilo’s touchscreen is able to show more traditional metering types, such as old style VU meters. Firmware version 7 added a powerful metering addition, a stereo third octave real time analyzer. As with all other Lynx products, Hilo is FPGA based, meaning new features, capabilities and graphics can be added at any time with a simple download.
Crucial for mastering and critical listening, Hilo offers world class, verifiable specifications. Every unit Lynx ships will meet or exceed these published specs:
LINE IN A/D PERFORMANCE
THD+N -114dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 121 dB, A-weighted, -60dBFS signal method
Frequency Resp. ± 0.01 dB, 20 – 20kHz
Crosstalk -140 dB maximum @ 1kHz, -1dBFS signal
LINE OUT D/A PERFORMANCE
THD+N -109dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 121 dB, A- weighted, -60dBFS signal method
Frequency Resp. ± 0.02 dB, 20 – 20kHz
Crosstalk -135 dB maximum @ 1kHz, -1dBFS signal
Hilo can be powered by standard 110-230V AC power or remotely with 9-18 volts DC, allowing the use of standard video battery packs or even auto cigarette lighter connections. Hilo measures 8.50 x 3.25 x 10.00 inches, weighs 6.75 pounds and is available with a silver or black front panel/knob option. Now available in Silver and Black, the US suggested retail price is $2495 with the LT-USB and $2795 with the LT-TB.
It is impossible to compare Hilo to other two channel AD and DA converters. In fact it is a unique product that is, at first, a little difficult to get your head around. Basically, Hilo replaces three different, critical components:
#1 Hilo is an analog to digital converter
#2 It is also a digital to analog converter. With most companies, these are two separate units.
#3 It is an independent headphone amplifier. The headphone section has its own, dedicated D/A converter. This provides two key benefits. First this allows Hilo to offer a headphone output with exceptional clarity and noise specifications. Second, due to Hilo’s internal 32 channel mixer, any input set can be routed to the headphone stereo output. This means that a mix that is entirely different from the analog outputs and monitors can be applied to the headphones.
Overview
Lynx Studio Technology is proud to present the Hilo Reference A/D D/A Converter System. With the pristine, open, transparent audio quality for which Lynx is known, Hilo (pronounced HE-low) provides two channels of mastering quality analog to digital conversion, up to six channels of digital to analog conversion, a secondary monitor output, and a world class independent headphone amplifier in a compact half-rack size. A first for the two-channel pro converter market, Hilo’s innovative 480 x 272 touch-screen provides a flexible and intuitive interface that can adapt to a particular application and be easily upgraded with enhancements and new features. Front panel controls support extensive signal routing and mixing, sample rate selection, clock source options, levels, metering and diagnostic features.
Hilo completely redefines and evolves the category of the two channel converter. Of utmost importance is the audio signal quality. The completely new design of the analog stages and converter topology for Hilo break new ground in terms of lowering distortion and noise while maintaining transparency for A/D and D/A conversion. Beyond that, Hilo offers extensive I/O capabilities and utilizes the latest FPGA technology with vast resources for control, routing, and signal processing capabilities. Also in development are diagnostic and analysis tools for Hilo. The LCD screen is a natural interface for these functions.
The digital or analog inputs can be routed to three separate analog outputs, Line Output (with 8 trim settings), Monitor Output, and Headphone Output. Each of these output pairs has its own dedicated DACs, allowing each to offer a unique mix. The Monitor and Headphone Outputs have volume controls, accessible via faders on the touch-screen or the single knob on the front (offering control in ½ dB increments). Another innovation, the Headphone section has its own dedicated D/A converter. This supports the creation of 32-channel headphone mixes independent of the main and monitor outputs, as well as providing specifications that rival those of dedicated headphone amps costing $1500 and more.
The digital section offers a wide range of inputs. AES/EBU inputs and outputs have transformer isolated balanced XLR connectors. S/PDIF input and output are available via transformer-coupled coax or optical (TOSLINK) connections. The Optical ports can also be used for up to eight ADAT channels. The ADAT input and output channels are completely independent from the AES/EBU or S/PDIF coax channels. The Lynx LT-USB (USB 2.0) or LT-TB (Thunderbolt) LSlot accessory is also included, for computer connectivity. The LT-HD for Pro Tools HD connectivity is also enabled. Lynx’s low jitter SynchroLock word clock is included, with Word Clock in and out connections available.
In total, Hilo has 12 total inputs, 16 total outputs plus 32 channels possible via its LSlot port. The unit’s FPGA powers its internal 32-channel mixer, which allows Hilo to offer the most versatile I/O and routing in the two channel converter genre.
In contrast to the concentrated and intricate back panel, Hilo’s front panel is elegant in its simplicity. It has a power switch, headphone jack, multipurpose control and a 480 x 272 pixel high resolution LCD touchscreen. This high-resolution screen does a lot more than simply replace the buttons on the front panel of most other converters. Of course it handles the basic settings and routing functions, clocking and level settings.
A second meter screen shows just two larger bar-graph style stereo bar meters. Any input or output set can be assigned to each meter. In addition to bar-graph meters common on most converters, Hilo’s touchscreen is able to show more traditional metering types, such as old style VU meters. Firmware version 7 added a powerful metering addition, a stereo third octave real time analyzer. As with all other Lynx products, Hilo is FPGA based, meaning new features, capabilities and graphics can be added at any time with a simple download.
Crucial for mastering and critical listening, Hilo offers world class, verifiable specifications. Every unit Lynx ships will meet or exceed these published specs:
LINE IN A/D PERFORMANCE
THD+N -114dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 121 dB, A-weighted, -60dBFS signal method
Frequency Resp. ± 0.01 dB, 20 – 20kHz
Crosstalk -140 dB maximum @ 1kHz, -1dBFS signal
LINE OUT D/A PERFORMANCE
THD+N -109dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 121 dB, A- weighted, -60dBFS signal method
Frequency Resp. ± 0.02 dB, 20 – 20kHz
Crosstalk -135 dB maximum @ 1kHz, -1dBFS signal
Hilo can be powered by standard 110-230V AC power or remotely with 9-18 volts DC, allowing the use of standard video battery packs or even auto cigarette lighter connections. Hilo measures 8.50 x 3.25 x 10.00 inches, weighs 6.75 pounds and is available with a silver or black front panel/knob option. Now available in Silver and Black, the US suggested retail price is $2495 with the LT-USB and $2795 with the LT-TB.
It is impossible to compare Hilo to other two channel AD and DA converters. In fact it is a unique product that is, at first, a little difficult to get your head around. Basically, Hilo replaces three different, critical components:
#1 Hilo is an analog to digital converter
#2 It is also a digital to analog converter. With most companies, these are two separate units.
#3 It is an independent headphone amplifier. The headphone section has its own, dedicated D/A converter. This provides two key benefits. First this allows Hilo to offer a headphone output with exceptional clarity and noise specifications. Second, due to Hilo’s internal 32 channel mixer, any input set can be routed to the headphone stereo output. This means that a mix that is entirely different from the analog outputs and monitors can be applied to the headphones.
Overview
Lynx Studio Technology is proud to present the Hilo Reference A/D D/A Converter System. With the pristine, open, transparent audio quality for which Lynx is known, Hilo (pronounced HE-low) provides two channels of mastering quality analog to digital conversion, up to six channels of digital to analog conversion, a secondary monitor output, and a world class independent headphone amplifier in a compact half-rack size. A first for the two-channel pro converter market, Hilo’s innovative 480 x 272 touch-screen provides a flexible and intuitive interface that can adapt to a particular application and be easily upgraded with enhancements and new features. Front panel controls support extensive signal routing and mixing, sample rate selection, clock source options, levels, metering and diagnostic features.
Hilo completely redefines and evolves the category of the two channel converter. Of utmost importance is the audio signal quality. The completely new design of the analog stages and converter topology for Hilo break new ground in terms of lowering distortion and noise while maintaining transparency for A/D and D/A conversion. Beyond that, Hilo offers extensive I/O capabilities and utilizes the latest FPGA technology with vast resources for control, routing, and signal processing capabilities. Also in development are diagnostic and analysis tools for Hilo. The LCD screen is a natural interface for these functions.
The digital or analog inputs can be routed to three separate analog outputs, Line Output (with 8 trim settings), Monitor Output, and Headphone Output. Each of these output pairs has its own dedicated DACs, allowing each to offer a unique mix. The Monitor and Headphone Outputs have volume controls, accessible via faders on the touch-screen or the single knob on the front (offering control in ½ dB increments). Another innovation, the Headphone section has its own dedicated D/A converter. This supports the creation of 32-channel headphone mixes independent of the main and monitor outputs, as well as providing specifications that rival those of dedicated headphone amps costing $1500 and more.
The digital section offers a wide range of inputs. AES/EBU inputs and outputs have transformer isolated balanced XLR connectors. S/PDIF input and output are available via transformer-coupled coax or optical (TOSLINK) connections. The Optical ports can also be used for up to eight ADAT channels. The ADAT input and output channels are completely independent from the AES/EBU or S/PDIF coax channels. The Lynx LT-USB (USB 2.0) or LT-TB (Thunderbolt) LSlot accessory is also included, for computer connectivity. The LT-HD for Pro Tools HD connectivity is also enabled. Lynx’s low jitter SynchroLock word clock is included, with Word Clock in and out connections available.
In total, Hilo has 12 total inputs, 16 total outputs plus 32 channels possible via its LSlot port. The unit’s FPGA powers its internal 32-channel mixer, which allows Hilo to offer the most versatile I/O and routing in the two channel converter genre.
In contrast to the concentrated and intricate back panel, Hilo’s front panel is elegant in its simplicity. It has a power switch, headphone jack, multipurpose control and a 480 x 272 pixel high resolution LCD touchscreen. This high-resolution screen does a lot more than simply replace the buttons on the front panel of most other converters. Of course it handles the basic settings and routing functions, clocking and level settings.
A second meter screen shows just two larger bar-graph style stereo bar meters. Any input or output set can be assigned to each meter. In addition to bar-graph meters common on most converters, Hilo’s touchscreen is able to show more traditional metering types, such as old style VU meters. Firmware version 7 added a powerful metering addition, a stereo third octave real time analyzer. As with all other Lynx products, Hilo is FPGA based, meaning new features, capabilities and graphics can be added at any time with a simple download.
Crucial for mastering and critical listening, Hilo offers world class, verifiable specifications. Every unit Lynx ships will meet or exceed these published specs:
LINE IN A/D PERFORMANCE
THD+N -114dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 121 dB, A-weighted, -60dBFS signal method
Frequency Resp. ± 0.01 dB, 20 – 20kHz
Crosstalk -140 dB maximum @ 1kHz, -1dBFS signal
LINE OUT D/A PERFORMANCE
THD+N -109dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 121 dB, A- weighted, -60dBFS signal method
Frequency Resp. ± 0.02 dB, 20 – 20kHz
Crosstalk -135 dB maximum @ 1kHz, -1dBFS signal
Hilo can be powered by standard 110-230V AC power or remotely with 9-18 volts DC, allowing the use of standard video battery packs or even auto cigarette lighter connections. Hilo measures 8.50 x 3.25 x 10.00 inches, weighs 6.75 pounds and is available with a silver or black front panel/knob option. Now available in Silver and Black, the US suggested retail price is $2495 with the LT-USB and $2795 with the LT-TB.
It is impossible to compare Hilo to other two channel AD and DA converters. In fact it is a unique product that is, at first, a little difficult to get your head around. Basically, Hilo replaces three different, critical components:
#1 Hilo is an analog to digital converter
#2 It is also a digital to analog converter. With most companies, these are two separate units.
#3 It is an independent headphone amplifier. The headphone section has its own, dedicated D/A converter. This provides two key benefits. First this allows Hilo to offer a headphone output with exceptional clarity and noise specifications. Second, due to Hilo’s internal 32 channel mixer, any input set can be routed to the headphone stereo output. This means that a mix that is entirely different from the analog outputs and monitors can be applied to the headphones.
4.759,00 €*
Diese Website verwendet Cookies, um eine bestmögliche Erfahrung bieten zu können. Mehr Informationen ...
